6 Axis Cnc Chinese Robot Arm Floor / Ceiling Mounting RS050N High Speed

Brand Name : KAWASAKI

Model Number : RS050N

Certification : CE

Place of Origin : China

MOQ : 1 set

Payment Terms : T/T, L/C, Western Union

Supply Ability : 50 sets /Month

Delivery Time : 7 working days after deposit

Packaging Details : One robot arm manipulator 6 axis cnc robot floor or celling mounting RS050N industrial robot arm for Kawasaki packing with fumigation wooden frame, WG: 1120 KG Controller and other parts packing with brown box, WG: 120 KG

Axis : 6

Product name : Robot arm manipulator 6 axis cnc robot floor or celling mounting RS050N industrial robot arm for Kawasaki

Installation : Floor or Celling mounting

Model : RS050N-B

Type : Articulated robot

Payload : 50kg

Reach : 2100mm

Mass : 555kg

Mounting : Floor, Ceiling

Color : Munsell 10GY9/1 equivalent

Contact Now

Robot arm manipulator 6 axis cnc robot floor or celling

mounting RS050N industrial robot arm for Kawasaki

Specification

RS050N SPECIFICATIONS
Type Articulated Robot
Degrees of Freedom (axes) 6
Payload (kg) 50
Max. Reach (mm) 2,100
Positional Repeatability (mm) ✽1 ±0.06
Motion Range (°) Arm Rotation (JT1) ±180
Arm Out-in (JT2) +140 - −105
Arm Up-down (JT3) +135 - −155
Wrist Swivel (JT4) ±360
Wrist Bend (JT5) ±145
Wrist Twist (JT6) ±360
Max. Speed (°/s) Arm Rotation (JT1) 180
Arm Out-in (JT2) 180
Arm Up-down (JT3) 185
Wrist Swivel (JT4) 260
Wrist Bend (JT5) 260
Wrist Twist (JT6) 360
Allowable Moment (N•m) Wrist Swivel (JT4) 210
Wrist Bend (JT5) 210
Wrist Twist (JT6) 130
Allowable Moment of Inertia (kg•m2) Wrist Swivel (JT4) 28
Wrist Bend (JT5) 28
Wrist Twist (JT6) 11
Mass (kg) 555
Mounting Floor, Ceiling
Installation Environment Ambient Temperature (°C) 0 - 45
Relative Humidity (%) 35 - 85 (No dew, nor frost allowed)
Controller / Power Requirements (kVA) E02 / 7.5
Protection Wrist : IP67 equivalent / Base axis : IP65 equivalent

Product Description

RS050N Robot

HIGH-SPEED, HIGH-PERFORMANCE ROBOT

The R series robots are setting the benchmark for all small to medium duty industrial robots. The compact design, along with industry leading speed, reach and work range make the R series robots ideal for a wide range of applications throughout a multitude of diverse industries.

6 Axis Cnc Chinese Robot Arm Floor / Ceiling Mounting RS050N High Speed

6 Axis Cnc Chinese Robot Arm Floor / Ceiling Mounting RS050N High Speed

6 Axis Cnc Chinese Robot Arm Floor / Ceiling Mounting RS050N High Speed

Product Information

6 Axis Cnc Chinese Robot Arm Floor / Ceiling Mounting RS050N High Speed
Our Service
1.Swift delivery
For common parts, we can deliver the goods within 3 days
2.Original products

All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.

3.Quality Assurance

4.Technical Support

Including inspection,repair and maintenance, we can give all kinds of technical support.

5.Quickly responce

Our staffs will keep 24h online and answer your question very quickly.
